Commercial range and heating times
| Model | Litres | Imp. gal | Dimension (mm) | Weight (kg) | Power | Heating time 28→60°C |
|---|---|---|---|---|---|---|
| PPS 136 | 136 | 30 | Ø510 × 1220 | 54.7 | 9 kW, 3 phase | 33 min |
| PPS 182 | 182 | 40 | Ø510 × 1600 | 67.6 | 9 kW, 3 phase | 45 min |
| PPS 227 | 227 | 50 | Ø510 × 1950 | 80.1 | 9 kW, 3 phase | 56 min |
| PPS 273 | 273 | 60 | Ø610 × 1600 | 93.0 | 9 kW, 3 phase | – |
| PPS 341 | 341 | 75 | Ø610 × 1930 | 112.5 | 9 kW, 3 phase | – |
| PPS 364 | 364 | 80 | Ø610 × 2040 | 117.6 | 9 kW, 3 phase | – |
| PPS 454 | 454 | 100 | Ø740 × 1650 | 142 | 9 kW | 112 min |
| PPS 908 | 908 | 200 | Ø990 × 1750 | 256 | 18 kW | 112 min |
| PPS 1362 | 1,362 | 300 | Ø990 × 2350 | 331 | 18 kW | 168 min |
| PPS 1816 | 1,816 | 400 | Ø1400 × 1900 | 408 | 18 kW | 225 min |
| PPS 2270 | 2,270 | 500 | Ø1400 × 2300 | 464 | 27 kW | 187 min |
| PPS 3632 | 3,632 | 800 | Ø1700 × 2400 | 649 | 27 kW | 300 min |
| PPS 4540 | 4,540 | 1,000 | Ø1700 × 2800 | 753 | 36 kW | 281 min |
| PPS 6810 | 6,810 | 1,500 | Ø2000 × 3000 | 1,270 | 36 kW | 422 min |
| PPS 9080 | 9,080 | 2,000 | Ø2000 × 3800 | 1,951 | 54 kW | 375 min |
Larger sizes (454 L and above) are customised to the requirement; power shown is the rating used for the heating time. Other sizes between those listed are available.
Where they are used
- Hotel and hostel hot water plant rooms.
- Hospital kitchens, wards and laundries.
- Restaurant and fast-food kitchens.
- Factories, canteens and workers' quarters.
- Schools, sports centres and clubhouses.
- As calorifiers for commercial heat pump systems.
Customised to your requirement
Sizes from 454 litres upward are customised: diameter, height, number of outlets, element rating and mounting can be adjusted to fit plant rooms and roof spaces. Tell us your daily hot water use, peak demand and available space, and Pecol will propose a tank.
Running a large electric storage heater all day is expensive. Adding a heat pump to heat the same tank can cut running costs by up to 75%.
Safety and maintenance
Each heater includes an automatic thermostat, safety pressure relief and access covers for servicing. Pecol provides maintenance services and spare parts including heating elements and thermostats.
Frequently asked questions
What is the largest storage water heater you make?
The standard range goes up to 9,080 L (2,000 gal) with 54 kW heating. Larger or special sizes can be made to order.
Do commercial storage heaters need three-phase power?
Yes, models from 136 L at 9 kW and above use three-phase supply.
